2018 Vol. 32, No. 5

Display Method:
Progress on Equation of State of Hydrogen and Deuterium
LIU Haifeng, ZHANG Gongmu, ZHANG Qili, SONG Hongzhou, LI Qiong, ZHAO Yanhong, SUN Bo, SONG Haifeng
2018, 32(5): 050101. doi: 10.11858/gywlxb.20180587
HTML PDF (276)
Abstract:

This paper reviews the research on the equation of state (EOS) for hydrogen and deuterium in the last twenty years.A quantitative analysis of the wide-range EOS for hydrogen and deuterium is given by combining the modified chemical free energy model and the modern computational techniques such as Qu...

Ⅰ-Ⅱ-Ⅲ Phase Transition of Bismuth under Magnetically Driven Ramp Wave Loading
CHONG Tao, TAN Fuli, WANG Guiji, ZHAO Jianheng, TANG Zhiping
2018, 32(5): 051101. doi: 10.11858/gywlxb.20180511
HTML PDF (223)
Abstract:

In this study, we developed a sample pre-heating system with the temperature range from room temperature to 180℃, matching with the magnetically driven apparatus CQ-4.The ramp wave compression experiments of bismuth under different initial temperatures (25-148℃) were carried out, using this pre-heat...

Crustal Dynamics Based on Magma Solidification
HUO Ruizhi, HE Duanwei
2018, 32(5): 051201. doi: 10.11858/gywlxb.20180599
HTML PDF (213)
Abstract:

The earth was in a molten state at the beginning of its formation.Over time, the magma on the earth's surface began to cool down and solidify, and the earth has gradually become such a trap structure.However, the cooling and liquid-solid transformation process of the earth materials continues until ...

High Pressure Raman Investigation of BiFeO3
HAN Xi, WU Ye, HUANG Haijun
2018, 32(5): 051202. doi: 10.11858/gywlxb.20170698
HTML PDF (243)
Abstract:

BiFeO3 is one of the most promising multiferroics that exhibits both magnetic and ferroelectric properties above room temperature.The room-temperature structure of BiFeO3 is a highly rhombohedrally distorted perovskite with space group R3c.In this study, we prepared BiFeO3 powder under high temperat...

Using PVDF Gauge to Study Grüneisen Parameter of Unreacted JB-9014 Insensitive Explosive
LIU Junming, ZHANG Xu, ZHAO Kang, QIN Shuang, PEI Hongbo, ZHANG Rong
2018, 32(5): 051301. doi: 10.11858/gywlxb.20180524
HTML PDF (185)
Abstract:

In order to obtain the Grüneisen parameter Γ of unreacted JB-9014 insensitive explosive, we carried out the one-dimensional plane impact experiment on JB-9014 explosive using a gun.In the experiment, the explosive sample was mounted between two copper plates, and two PVDF gauges were installed at th...

Experiment and Numerical Calculation on Launching Performance of Two-Stage Light Gas Gun Driven by Gas Reaction
DONG Shi, MENG Chuanmin, GU Wei, PENG Xusheng, ZHANG Botao, XIAO Yuanlu, FANG Maolin, XIANG Yaomin, WANG Xiang
2018, 32(5): 053201. doi: 10.11858/gywlxb.20180528
HTML PDF (175)
Abstract:

In this paper, the launching performance of a developed 20/57 mm two-stage light gas gun was studied, of which the driving energy is supplied by the gaseous chemical reaction.The experimental results show that the relationship between the chemical energy and the kinetic energy of the projectile can ...

Preparation of Cobalt-Doped Magnesium Oxide Pressure-Transmitting Medium with Solid Reaction Process
WU Jingjun, HE Duanwei, WANG Qiang, ZHANG Jiawei, LIU Jin
2018, 32(5): 053301. doi: 10.11858/gywlxb.20180564
HTML PDF (229)
Abstract:

In this study, magnesium oxide (MgO) doped by cobalt (Co) was prepared as pressure-transmitting medium, by solid reaction process.The starting material is a pre-compressed mixture of MgO and cobalt oxide (CoO), which was mixed for 8 h and compressed at 200 MPa, and then treated at 1 200℃.The as-prep...

Numerical Analysis of Segmented PELE Penetrating Multi-layer Target
ZHOU Jingyuan, DING Liangliang, TANG Wenhui, RAN Xianwen
2018, 32(5): 054101. doi: 10.11858/gywlxb.20180514
HTML PDF (210)
Abstract:

To achieve efficient damage, we simulated the penetration of segmented penetrator with enhanced lateral effect (PELE) on the 4-layer metal target and analyzed the influence of projectile velocity and layer thickness on the terminal effect.The results showed that the segmented PELE projectile perform...

Dynamic Buckling of Functionally Graded Cylindrical Shells under Axial Loading
ZHOU Jiahua, YANG Qiang, HAN Zhijun, LU Guoyun
2018, 32(5): 054102. doi: 10.11858/gywlxb.20180502
HTML PDF (183)
Abstract:

Based on the Donnell shell theory and classical shell theory, we established the dynamic buckling governing equation of functionally graded cylindrical shell under axial load using Hamilton principle.According to the expression of the radial displacement based on the circumferential continuity of cy...

Experimental Investigation on the Characteristics of Unstability at Liquid-Liquid Tilted Interface Induced by Rayleigh-Taylor Instability
JIANG Rongbao, HUANG Xilong, ZOU Liyong, SHI Honghui, WU Jun
2018, 32(5): 054201. doi: 10.11858/gywlxb.20180512
HTML PDF (178)
Abstract:

In this research, we experimentally investigated the characteristics of the turbulent mixing zone induced by Rayleigh-Taylor (R-T) instability under different accelerations.We used the high-speed shadowgraph to study the evolution of the interface composed with the silicone oil/potassium iodide solu...

Dynamical Fragmentation of Steel Cylinders Subjected to Internal Explosive Detonations
CHEN Hu, SHEN Zhengxiang, WANG Du, CHEN Dingyue, YUAN Shuqiang
2018, 32(5): 054202. doi: 10.11858/gywlxb.20180527
HTML PDF (201)
Abstract:

Explosively driven fragmentation of material is a highly complex phenomenon.In this study, we evaluated the influence of explosive on the intrinsic fragmentation characteristics using hollow cylindrical steel shells, and investigated a new universal assessment criteria for the fragmentation of cylin...

Effect of Sectional Geometric Parameters on Axial Impact Response of Hat-Section Beam
TIAN Ze, HAN Yang, YIN Xiaowen, XIN Hao, ZHAO Longmao, LI Zhiqiang
2018, 32(5): 054203. doi: 10.11858/gywlxb.20180521
HTML PDF (162)
Abstract:

As the major part of the vehicle front side member, the hat-section beam structure's deformation mode and energy absorption characteristics under the axial impact is the main reference index in the design of automobile passive safety.In this study, we carried out a drop hammer axial impact test and ...

Experimental Investigation on Load Characteristics and Structure Response of Finite-Size Plate Subjected to Underwater Explosions
LIU Libin, LI Haitao, DIAO Aimin, WANG Xiaoqiang
2018, 32(5): 055101. doi: 10.11858/gywlxb.20180516
HTML PDF (183)
Abstract:

In order to study the loading characteristics of underwater explosion shock wave and bubble near the structural boundary, we designed and tested several plate models.By changing the ratio of stand-off to the maximum bubble radius, the flat thickness and other parameters, we analyzed the bubble pulsa...

Numerical Simulation of Anti-Penetration of Laminated Steel Plate by Hemispherical-Nosed Projectile Using SPH
QIANG Hongfu, SUN Xinya, WANG Guang, CHEN Fuzhen, SHI Chao, HUANG Quanzhang
2018, 32(5): 055102. doi: 10.11858/gywlxb.20170664
HTML PDF (160)
Abstract:

With the wide application of high strength and high impact-resistant steel structures in armor protection of armor, arsenal protective doors and other military facilities, the impact-resistant properties of steel structures become a major focus and hot spot in defense research.In this paper, we simu...

Study on the Penetration Performance of Different Shaped DU Alloy
WU Fanda, ZHAO Handong, SHAO Xianfeng, MA Shanshan, LIU Sheng, ZHANG Chengjian
2018, 32(5): 055103. doi: 10.11858/gywlxb.20180504
HTML PDF (26)
Abstract:

To study the penetration performance of different shapes of a DU alloy fragment, we performed an experiment on a Q235B steel target with a thickness of 20 mm and obtained its terminal ballistic marriage parameters of cylindrical DU alloy fragment penetration.Then, we carried out the corresponding si...

Penetration Deceleration Signal Processing Method with Ensemble Empirical Mode Decomposition and Consecutive Mean Square Error
TANG Lin, CHEN Gang, WU Hao
2018, 32(5): 055104. doi: 10.11858/gywlxb.20180518
HTML PDF (208)
Abstract:

The extraction of rigid-body deceleration characteristic plays a significant role in the research of anti-hard-target weapons and related areas.In this paper, we investigated the methods of processing on-board recorded penetration deceleration data.The intrinsic mode functions were separated from th...

Numerical Study on Ballistic Resistance of Metal Perforated Armor to Projectile Impact
QIN Qinghua, CUI Tianning, SHI Qian, JIN Yongxi, ZHANG Jianxun
2018, 32(5): 055105. doi: 10.11858/gywlxb.20180530
HTML PDF (226)
Abstract:

In this paper, we numerically studied the ballistic resistance of the metal perforated armor to the high-velocity projectile, and analyzed in detail the effects of various factors on its ballistic resistance, including the impact velocity, the oblique angle, the hitting location and the size of hole...

Numerical Simulation of Protective Envelope of Explosive Reaction Armor
SUN Jianjun, LI Rujiang, WAN Qinghua, ZHANG Ming, YANG Yue, SUN Miao
2018, 32(5): 055106. doi: 10.11858/gywlxb.20180523
HTML PDF (198)
Abstract:

In this work, the three-dimensional finite element analysis software LS-DYNA was used to numerically simulate the ballistic performance of explosive reactive armor at different impact points, and the comparative experiments were also carried out in order to obtain the protective envelope of the expl...

Structural Optimum Design and Pre-stress Simulation of Fiber Housing for Railgun
XIAO Hongcheng, YIN Dongmei, LIN Qinghua, LI Baoming
2018, 32(5): 055107. doi: 10.11858/gywlxb.20170594
HTML PDF (199)
Abstract:

The structural optimization design of filament winding housing for a railgun barrel is introduced.The thickness of fiber laminates, the winding angle and the stacking sequence of fibers for a 50 mm circular bore composite barrel are investigated for structural optimization.Numerical simulation of ra...

Seepage of Marine-Terrigenous Facies Coal Measures Shale
ZHANG Hongxue, LIU Weiqun
2018, 32(5): 055901. doi: 10.11858/gywlxb.20180556
HTML PDF (182)
Abstract:

Using a pulse decay permeameter, we conducted a combination of laboratory experiments to study permeability evolution of marine-terrigenous facies coal measures shale under reservoir conditions, and obtained the permeability of coal measures shale under different stress states, and furthermore analy...
