2017 Vol. 31, No. 4

column
Display Method:
Influence of the Strength of Materials on Pressure Calibration under Non-Hydrostatic Compression
ZHANG Qiang, PENG Fang, LIU Dong-Qiong, FAN Cong, LIANG Hao, GUAN Shi-Xue, TAN Li-Jie
2017, 31(4): 353-357. doi: 10.11858/gywlxb.2017.04.001
HTML PDF (201)
Abstract:

In this paper, we carried out experimental studies on the influence of the strength of materials on the pressure calibration under non-hydrostatic compression using the diamond anvil cell and synchrotron radiation X-ray diffraction technology.Pt and Au were used as the pressure marker in the same hi...

Dynamic Crushing Response of Self-Similar Second Order Hierarchical Square Honeycombs
ZHANG Yue, LI Shi-Qiang, WANG Zhi-Hua, WU Gui-Ying
2017, 31(4): 358-363. doi: 10.11858/gywlxb.2017.04.002
HTML PDF (214)
Abstract:

Out-of-plane dynamic crushing response of self-similar second order hierarchical square honeycombs under impact loading was simulated using ABAQUS in the present study to investigate the influence of the aperture size, the yield stress of parent material and the impact velocity on the crushing model...

Effects of Strain Rate and Porosity on the Compressive Behavior of Porous Titanium with Regular Pores
WANG Jing, REN Hui-Lan, SHEN Hai-Ting, NING Jian-Guo
2017, 31(4): 364-372. doi: 10.11858/gywlxb.2017.00.003
HTML PDF (10)
Abstract:

Using a material testing machine and the split Hopkinson pressure bar (SHPB) system, we investigated the quasi-static and dynamic compressive behaviors of porous titanium with regular pores, and studied the effects of the strain rate and porosity on the Young's modulus, yield strength and energy abs...

Mechanical Property and Failure Mechanism of Composite Laminates Containing a Circular Hole under Tension
ZHU Hao, GUO Zhang-Xin, SONG Lu-Bin, WANG Zhi-Hua, LI Yong-Cun
2017, 31(4): 373-381. doi: 10.11858/gywlxb.2017.04.004
HTML PDF (366)
Abstract:

In order to set up a three dimensional damage model for composite laminates with a circular hole, based on the failure criteria proposed by Linde et al., we at first implemented the user-defined material subroutine UMAT in the finite element code ABAQUS using the factors of fiber and matrix to chara...

Experimental Study of Fragmentation Behavior of ExplodedTA2 Alloy Cylinders with Varied Charge
PAN Shun-Ji, YU Xin-Lu, DONG Xin-Long
2017, 31(4): 382-388. doi: 10.11858/gywlxb.2017.04.005
HTML PDF (134)
Abstract:

The explosively driven fragmentation of ductile metals is a complex phenomenon, for that the fracture modes and mechanisms are affected by materials, configuration and explosive energy in different ways.In this research, we investigated experimentally the deformation and fracture behavior of the exp...

Effect of Ferrocene Precursor Mass on Gaseous Detonation Synthesisof Carbon Nanotubes
YANG Rui, LI Xiao-Jie, YAN Hong-Hao, KONG Ling-Jie
2017, 31(4): 389-395. doi: 10.11858/gywlxb.2017.04.006
HTML PDF (224)
Abstract:

In the present study we studied the influence of the mass of ferrocene precursors on the synthesis of carbon nanotubes with methane and oxygen as the explosive sources.The morphology and structure of the carbon nanotubes were characterized using X-ray diffraction, transmission electron microscopy an...

Quantum Calculation for Equation of State of Compressed Solid Argon
ZHENG Xing-Rong, CHEN Hai-Jun, GAO Xiao-Hong, LI Ji-Hong, SONG Xiao-Yong
2017, 31(4): 396-402. doi: 10.11858/gywlxb.2017.04.007
HTML PDF (116)
Abstract:

Based on the first-principles and using the double cluster with full single and double excitations plus perturbative treatment of triples (CCSD(T)) and the aug-cc-pVQZ basis set, many-body contributions to the cohesive energy, the zero-point vibration energy and the equation of state of solid argon ...

Detonation Modification of Multi-Walled Carbon Nanotubes
ZHAO Tie-Jun, YAN Hong-Hao, LI Xiao-Jie, WANG Yang
2017, 31(4): 403-408. doi: 10.11858/gywlxb.2017.04.008
HTML PDF (181)
Abstract:

In order to study the influence of detonation reaction on the morphology and phase of multi-walled carbon nanotubes (MWCNTs), the mixed explosives, made from MWCNTs and RDX with a given mass ratio, were detonated in the reaction kettle.The samples before and after detonation were characterized using...

One-Dimensional Magneto-Hydrodynamics Calculation and Analysis of Implosion Magnetic Flux Compression Process
LU Yu, GU Zhuo-Wei
2017, 31(4): 419-425. doi: 10.11858/gywlxb.2017.04.010
HTML PDF (150)
Abstract:

In this work we modified the 1D implosion and the MHD code—MC11D by introducing the equation of state (EOS) in analytical form into the program.Then, using the modified code, we simulated a cylindrical implosion magnetic flux compression experiment on the copper sample and obtained the velocity hist...

Dynamic Deformation Image Deblurring and Image Processing for Digital Imaging Correlation Measurement
GUO Xiang, LI Yu-Long, SUO Tao, LIU Hui-Fang, ZHANG Chao
2017, 31(4): 426-432. doi: 10.11858/gywlxb.2017.00.011
HTML PDF (193)
Abstract:

In this research, we proposed a method for deblurring of images captured in the dynamic deformation of materials.By this method, deblurring was achieved based on a dynamic-based approach, which was used to estimate the point spread function (PSF) during the camera exposure window.The deconvolution p...

Influence of Charge Structure on the Cook-off Temperature Distribution of Solid Rocket Motor
YANG Xiao, ZHI Xiao-Qi, YANG Bao-Lang, LI Juan-Juan
2017, 31(4): 433-442. doi: 10.11858/gywlxb.2017.04.012
HTML PDF (234)
Abstract:

To investigate the influence of the charge structure on the cook-off characteristics of the solid rocket motor, we established 3 simplified cook-off models with 3 different charge structures, including the composite, the mono tube and the star tube, for the solid rocket motor with HTPE propellant.We...

Theoretical Analysis of the Interaction between the Plate Structure and Strong Shock Wave in Underwater Explosion
LUO Ze-Li, ZHOU Zhang-Tao, MAO Hai-Bin, LIU Jian-Hu
2017, 31(4): 443-452. doi: 10.11858/gywlxb.2017.04.013
HTML PDF (361)
Abstract:

To investigate the fluid-structure interaction of the one-dimensional strong shock wave with the plate, we took the compressibility of fluid and structural material into account and, by introducing state of equation of water and structural material into our theoretical analysis, obtained the reflect...

Shockwave Characteristics of Shaped Charge Exploded Underwater
WANG Chang-Li, ZHOU Gang, MA Kun, CHEN Chun-Lin, ZHAO Nan, FENG Na
2017, 31(4): 453-461. doi: 10.11858/gywlxb.2017.04.014
HTML PDF (166)
Abstract:

In this research, to investigate the pressure distribution of the shaped charge explosive in the underwater near-field, we conducted both experimental studies and numerical simulation and, by comparing the results from the simulation with those from the experiments, validated both the numerical mode...

Multi-Factors Analysis of Annular Shaped Charge Capability of Penetrating Target Board
MA Yan, ZHAO Han-Dong, HUANG Xin
2017, 31(4): 462-468. doi: 10.11858/gywlxb.2017.04.015
HTML PDF (149)
Abstract:

The relationship between the structural parameters and penetration capacity of annular shaped charge is hard to express by analytical mathematical formulas, so it is meaningful to establish a model to describe this relationship using the grey relational analysis theory.In our study, the orthogonal t...

Welding Thin-Walled Projectiles for Penetrating Multi-Layered Reinforced Concrete Targets
DAI Xiang-Hui, DUAN Jian, ZHOU Gang, CHU Zhe, WANG Ke-Hui, GU Ren-Hong, LI Hu-Wei, YANG Hui, LI Peng-Jie, LIU Heng-Ze
2017, 31(4): 469-477. doi: 10.11858/gywlxb.2017.04.016
HTML PDF (162)
Abstract:

To appraise the technical feasibility of welding thin-walled projectile for penetrating multi-layered reinforced concrete targets, we used the finite element method to simulate the penetration process and designed a set of comparative tests based on the simulation results.The welded thin-walled proj...

Shock Induced Reaction Process of Ti-Si Reactive Powder
CUI Nai-Fu, CHEN Peng-Wan, ZHOU Qiang, ZHOU Bing-Bing
2017, 31(4): 478-485. doi: 10.11858/gywlxb.2017.04.017
HTML PDF (198)
Abstract:

To find out whether there exists an increased shock wave velocity when the Ti-Si reactive powder is loaded by shock, we used the gas gun to drive the flyer to impact the active Ti-Si powder and initiate its reaction.In the process of the powder's self-propagating reaction experiment, high speed came...

Formation and Penetration Performane of Multi-Explosviely Formed Projectiles
CAO Ming-Yang, WANG Jin-Xiang, HAO Chun-Jie, SONG Hai-Ping, ZHANG Ya-Ning, ZHOU Lian, ZHOU Nan, TANG Kui
2017, 31(4): 486-493. doi: 10.11858/gywlxb.2017.04.018
HTML PDF (222)
Abstract:

In order to improve the formation and penetration performance of multi-explosively formed projectiles (MEFP), we analyzed the influence of the charge cover (both its shape and wall thickness), the shell thickness, the explosive initiation modes as well as the fragments bracket on the projectiles for...

Effect of High Pressure Processing on Quality and Structure of Lateolabrax Japonicus Fillets during Cold Storage
ZHAO Hong-Qiang, WU Jin-Xin, ZHANG Yuan-Yi, LAN Wei-Qing, LIU Shu-Cheng, SUN Xiao-Hong, XIE Jing
2017, 31(4): 494-504. doi: 10.11858/gywlxb.2017.04.019
HTML PDF (506)
Abstract:

In the present work, to investigate the effects of high pressure processing (HPP) treatment on the quality and structure of the perch (Lateolabrax japonicas) fillets during cold storage, we treated samples with different HPP conditions (200, 250 and 300MPa for 9min) and then stored them at 4℃ respec...

Effects of Strain Rate and Porosity on the Compressive Behavior of Porous Titanium with Regular Pores
WANG Jing, REN Hui-Lan, SHEN Hai-Ting, NING Jian-Guo
2017, 31(4): 364-372. doi: 10.11858/gywlxb.2017.04.003
PDF (312)
Abstract:
Using a material testing machine and the split Hopkinson pressure bar (SHPB) system,we investigated the quasi-static and dynamic compressive behaviors of porous titanium with regular pores,and studied the effects of the strain rate and porosity on the Youngs modulus,yield strength and energy absorpt...
研究论文
Influence of Bend Structure on Air ShockwaveGenerated from Gas Explosion in theStraight Tunnel before the Bend
PANG Lei, LIU Hai-Ying, XIA Deng-You, LÜ Peng-Fei
2017, 31(4): 409-418. doi: 10.11858/gywlxb.2017.04.009
HTML PDF (61)
Abstract:

The bend structure is one of the most basic building elements of a coal tunnel.A good understanding of its influence on the gas explosion is essential for estimating the tunnel's blast resistance and thus for optimizing the tunnel's design.In the present work, we studied the influence of the bend st...
