High-Pressure Viscosity Measurement of Liquids Based on Diamond Anvil Cell
-
摘要: 研制了一种基于金刚石对顶砧的液体高压黏度测量装置。该装置由金刚石对顶砧、显微镜和CCD探测器构成，利用红宝石荧光标定压力，通过落球法可简单方便地实现不同压力下液体黏度的测量。利用该装置，测量了高压下丙三醇的黏度，测量结果与已发表的实验数据吻合得很好，验证了测量装置的可靠性。Abstract: We developed a device for measuring high-pressure viscosity of liquids.The device consists of a diamond anvil cell, a microscope and a CCD detector, by which pressures can be determined using the ruby fluorescence technique.It is simple and convenient to measure the viscosities of liquids under different pressures with the falling-ball method.Using this device, we successfully obtained the viscosities of glycerin under high pressure, which are in good agreement with the published data, suggesting that our measuring device and method are both reliable.
-
Key words:
- viscosity /
- diamond anvil cell /
- falling-ball method /
- glycerin
-
图 1 高压黏度测量装置示意图
Figure 1. Schematic diagram of viscosity measurement under high pressure
图 3 0.23 GPa压力下微球的下落距离随时间变化的关系
Figure 3. Falling distance of the microsphere vs. time under 0.23 GPa
表 1 298.0 K时不同压力下丙三醇黏度的测量值
Table 1. Measured viscosities of glycerin at 298.0 K and different pressures
p/(GPa) η/(mPa·s) lgη 0.000 1 7.01×102 2.85 0.03 8.28×102 2.92 0.09 1.03×103 3.01 0.15 1.34×103 3.13 0.19 1.74×103 3.24 0.23 2.47×103 3.39 0.30 2.78×103 3.44 0.33 3.24×103 3.51 0.40 5.90×103 3.77 0.48 8.99×103 3.95 0.61 1.60×104 4.20 0.83 3.29×104 4.52 0.98 9.13×104 4.96 1.03 1.09×105 5.04 1.18 1.35×105 5.13 1.36 3.12×105 5.49 1.39 4.06×105 5.61 1.54 5.40×105 5.73 1.70 1.57×106 6.19 1.84 3.08×106 6.49 1.96 4.33×106 6.64 2.09 6.57×106 6.82 2.20 1.03×107 7.01 2.29 1.88×107 7.28
下载: 导出CSV
-
[1] 时静洁, 陈利平, 陈网桦, 等.基于分子形状与电性拓扑状态指数预测烃类物质粘度的研究[J].南京理工大学学报, 2014, 38(4):575-580. doi: 10.3969/j.issn.1005-9830.2014.04.022SHI J J, CHEN L P, CHEN W H, et al.Prediction of viscosity for hydrocarbons by molecular shape indices and electrotopological state indices[J].Journal of Nanjing University of Science and Technology, 2014, 38(4):575-580. doi: 10.3969/j.issn.1005-9830.2014.04.022 [2] 杨斌, 程杰, 李国芳.浅谈旋转粘度计的使用[J].现代制造技术与装备, 2014(2):52-58. http://d.old.wanfangdata.com.cn/Periodical/xdzzjsyzb201402025YANG B, CHENG J, LI G F.Discussion on the use of rotational viscometer[J].Modern Manufacturing Technology and Equipment, 2014(2):52-58. http://d.old.wanfangdata.com.cn/Periodical/xdzzjsyzb201402025 [3] MALANOWSKI A, ROSTOCKI A J, KIEŁCZYNSKI P, et al.Viscosity and compressibility of diacylglycerol under high pressure[J].High Pressure Res, 2013, 33(1):178-183. doi: 10.1080/08957959.2013.775649 [4] COMUÑAS M J P, BAYLAUCQ A, BONED C, et al.High-pressure measurements of the viscosity and density of two polyethers and two dialkyl carbonates[J].Int J Thermophys, 2001, 22(3):749-768. doi: 10.1023/A:1010770831215 [5] ZEBERG-MIKKELSEN C K, CANET X, BAYLAUCQ A, et al.High-pressure viscosity and density behavior of ternary mixtures:1-methylnaphthalene+n-tridecane+2, 2, 4, 4, 6, 8, 8-heptamethylnonane[J].Int J Thermophys, 2001, 22(6):1691-1726. doi: 10.1023/A:1013134832244 [6] SUZUKI A, OHTANI E, TERASAKI H, et al.Viscosity of silicate melts in CaMgSi2O6-NaAlSi2O6 system at high pressure[J].Phys Chem Miner, 2005, 32(2):140-145. doi: 10.1007/s00269-005-0452-0 [7] ASSAEL M J, MYLONA S K.A novel vibrating-wire viscometer for high-viscosity liquids at moderate pressures[J].J Chem Eng Data, 2013, 58(4):993-1000. doi: 10.1021/je301306e [8] MATSUO S, MAKITA T.Viscosity of methanol and 2-methyl-2-propanol mixtures under high pressures[J].Int J Thermophys, 1991, 12(3):459-468. doi: 10.1007/BF00502362 [9] KUMAGAI A, YOKOYAMA C.Viscosity of aqueous solutions of CO2 at high pressures[J].Int J Thermophys, 1998, 19(5):1315-1323. doi: 10.1023/A:1021923316701 [10] KIRAN E, SEN Y L.High-pressure viscosity and density of n-alkanes[J].Int J Thermophys, 1992, 13(3):411-442. doi: 10.1007/BF00503880 [11] MATTISCHEK H P, SOBCZAK R.A new cell for measurement of viscosity under high pressure[J].Meas Sci Technol, 1994, 5(7):782-785. doi: 10.1088/0957-0233/5/7/004 [12] DOBSON D P, JONES A P, RABE R, et al.In-situ measurement of viscosity and density of carbonate melts at high pressure[J].Earth Planet Sci Lett, 1996, 143(1):207-215. doi: 10.1016-0012-821X(96)00139-2/ [13] SUZUKI A, OHTANI E, FUNAKOSHI K, et al.Viscosity of albite melt at high pressure and high temperature[J].Phys Chem Miner, 2002, 29(3):159-165. doi: 10.1007/s00269-001-0216-4 [14] HERBST C A, KING H E Jr, GAO Z, et al.Dynamic light scattering measurements of high-pressure viscosity utilizing a diamond anvil cell[J].J Appl Phys, 1992, 72(3):838-844. doi: 10.1063/1.351756 [15] COOK R L, HERBST C A, KING H E Jr.High-pressure viscosity of glass-forming liquids measured by the centrifugal force diamond anvil cell viscometer[J].J Phys Chem, 1993, 97(10):2355-2361. doi: 10.1021/j100112a041 [16] PIERMARINI G J, FORMAN R A, BLOCK S.Viscosity measurements in the diamond anvil pressure cell[J].Rev Sci Instrum, 1978, 49(8):1061-1066. doi: 10.1063/1.1135514 [17] ABRAMSON E H.The shear viscosity of supercritical oxygen at high pressure[J].J Chem Phys, 2005, 122(8):084501. doi: 10.1063/1.1849166 [18] TATEIWA N, HAGA Y.Evaluations of pressure-transmitting media for cryogenic experiments with diamond anvil cell[J].Rev Sci Instrum, 2009, 80(12):123901. doi: 10.1063/1.3265992 [19] COOK R L, KING H E Jr, HERBST C A, et al.Pressure and temperature dependent viscosity of two glass forming liquids:glycerol and dibutyl phthalate[J].J Chem Phys, 1994, 100(7):5178-5189. doi: 10.1063/1.467276 -
