钢筋混凝土靶板在弹丸冲击及爆炸载荷下响应的数值模拟

孟阳; 文鹤鸣

doi:10.11858/gywlxb.2011.04.014

钢筋混凝土靶板在弹丸冲击及爆炸载荷下响应的数值模拟

doi: 10.11858/gywlxb.2011.04.014

孟阳,
文鹤鸣

中国科学技术大学中国科学院材料力学行为与设计重点实验室，安徽合肥 230027

详细信息

通讯作者:
文鹤鸣

计量
- 文章访问数: 7583
- HTML全文浏览量: 275
- PDF下载量: 509
出版历程
- 收稿日期: 2009-11-17
- 修回日期: 2010-01-26
- 刊出日期: 2011-08-15

Numerical Simulation of the Response of Reinforced Concrete Slabs to Projectile Impact or Explosive Loading

CAS Key Laboratory for Mechanical Behavior and Design of Materials, University of Science and Technology of China, Hefei 230027, China

More Information

Corresponding author: WEN He-Ming

摘要

摘要: 采用HJC混凝土损伤本构模型及LS-DYNA的流固耦合算法，分别对钢筋混凝土靶板在弹丸冲击和爆炸载荷作用下的响应进行了有限元数值模拟，其中模拟参数由实验数据拟合重新获取。将模拟结果与实验结果和经验公式进行对比分析，结果表明：数值模拟再现了弹体贯穿靶板过程中的开坑、隧道及漏斗碎裂区，计算得到的弹体弹道极限及残余速度与实验数据吻合较好；此外，数值模拟也很好地再现了炸药爆炸后冲击波的传播过程以及爆炸载荷作用下混凝土的破坏情况，模拟结果与实验现象具有良好的一致性。
- 钢筋混凝土靶板 /
- 弹丸撞击 /
- 爆炸加载 /
- 数值模拟
Abstract: Numerical simulation is first conducted herein of the perforation of reinforced concrete slabs by an ogival-nosed projectile using LS-DYNA. The triaxial test data reported in this paper for the 48 MPa concrete are used to determine the values of the parameters employed in the Holmquist-Johnson-Cook (HJC) model. It is shown that the numerical simulations correlate well with the experimental observations in terms of ballistic limit, residual velocity, impact crater, penetration tunnel and scabbing crater. The response of reinforced concrete slabs to explosive loading is also studied numerically by the fluidsolid coupled method of LS-DYNA. The simulation reproduces the transient process of the shock wave and the main rupture process of the slabs. The numerically obtained pressure-time histories are found to be in reasonable agreement with those predicted by the empirical equations; the failure patterns obtained by the numerical simulation are found to be similar to those obtained experimentally.
- reinforced concrete slab /
- projectile impact /
- explosive loading /
- numerical simulation

HTML全文

参考文献(22)

Polanco-Loria M, Hopperstad O S, Borvik T, et al. Numerical Predictions of Ballistic Limits for Concrete Slabs Using a Modified Version of the HJC Concrete Model [J]. Int J Impact Eng, 2008, 35(5): 290-303.

Wu H J, Huang F L, Jin Q K, et al. Numerical Simulation on Perforation of Reinforced Concrete Targets [J]. Explosion and Shock Waves, 2003, 23(6): 545-550. (in Chinese)

武海军, 黄风雷, 金乾坤, 等. 弹体贯穿钢筋混凝土数值模拟 [J]. 爆炸与冲击, 2003, 23(6): 545-550.

Qu M, Chen X W. Numerical Simulations on Perforation of Reinforced Concrete Targets [J]. Explosion and Shock Waves, 2008, 28(4): 341-349. (in Chinese)

屈明, 陈小伟. 钢筋混凝土穿甲的数值模拟 [J]. 爆炸与冲击, 2008, 28(4): 341-349.

Wang T Y, Ren H Q, Zhang L J, et al. Numerical Simulation of General Bomb Penetration into Pre-Stress Reinforced Concrete Containment [J]. Engineering Mechanics, 2005, 22(5): 126-130. (in Chinese)

王天运, 任辉启, 张力军, 等. 常规装药侵彻预应力钢筋混凝土安全壳数值模拟 [J]. 工程力学, 2005, 22(5): 126-130.

He T, Wen H M. Determination of the Analytical Forcing Function of Target Response and Its Applications in Penetration Mechanics [J]. Journal of University of Science and Technology of China, 2007, 37(10): 1249-1261. (in Chinese)

何涛, 文鹤鸣. 靶体响应力函数的确定方法及其在侵彻力学中的应用 [J]. 中国科学技术大学学报, 2007, 37(10): 1249-1261.

Krauthammer T, Otani R K. Mesh, Gravity and Load Effects on Finite Element Simulations of Blast Loaded Reinforced Concrete Structures [J]. Comput Struct, 1997, 63(6): 1113-1120.

Fang Q, Liu J C, Zhang Y D, et al. Finite Element Analysis of Failure Modes of Blast-Loaded R/C Beams [J]. Engineering Mechanics, 2001, 18(2): 1-8. (in Chinese)

方秦, 柳锦春, 张亚栋, 等. 爆炸荷载作用下钢筋混凝土梁破坏形态有限元分析 [J]. 工程力学, 2001, 18(2): 1-8.

Wu H J, Huang F L, Fu Y S, et al. Numerical Simulation of Reinforced Concrete Breakage under Internal Blast Loading [J]. Journal of Beijing Institute of Technology, 2007, 27(3): 200-204. (in Chinese)

武海军, 黄风雷, 付跃升, 等. 钢筋混凝土中爆炸破坏效应数值模拟分析 [J]. 北京理工大学学报, 2007, 27(3): 200-204.

Zhou X Q, Kuznetsov V A, Hao H, et al. Numerical Prediction of Concrete Slab Response to Blast Loading [J]. Int J Impact Eng, 2008, 35(10): 1186-1200.

Tu Z G, Lu Y. Evaluation of Typical Concrete Material Models Used in Hydrocodes for High Dynamic Response Simulations [J]. Int J Impact Eng, 2009, 36(1): 132-146.

Holmquist T J, Johnson G R, Cook W H. A Computational Constitutive Model for Concrete Subjected to Large Strains, High Strain Rates, and High Pressures [A]//Proceedings of the 14th international Symposium on Ballistics [J]. Quebec, Canada, 1993: 591-600.

Malvar L J, Crawford J E, Wesevich J W, et al. A Plasticity Concrete Material Model for DYNA3D [J]. Int J Impact Eng, 1997, 19(9-10): 847-873.

Hanchak S J, Forrestal M J, Young E R, et al. Perforation of Concrete Slabs with 48 MPa (7 ksi) and 140 MPa (20 ksi) Unconfined Compressive Strengths [J]. Int J Impact Eng, 1992, 12(1): 1-7.

Hallquist J O. LS-DYNA3D Theoretical Manual [Z]. Livermore, California, USA: Livermore Software Technology Corporation, 1997.

Zhang F G, Li E Z. A Method to Determine the Parameters of the Model for Concrete Impact and Damage [J]. Journal of Ballistics, 2001, 13(4): 12-16. (in Chinese)

张凤国, 李恩征. 混凝土撞击损伤模型参数的确定方法 [J]. 弹道学报, 2001, 13(4): 12-16.
