铜射流侵彻穿孔处的温度及微观组织研究

陈昊; 陶钢

doi:10.11858/gywlxb.2011.04.010

铜射流侵彻穿孔处的温度及微观组织研究

doi: 10.11858/gywlxb.2011.04.010

陈昊,
陶钢

南京理工大学能源与动力工程学院，江苏南京 210094

详细信息

通讯作者:
陈昊

计量
- 文章访问数: 7778
- HTML全文浏览量: 365
- PDF下载量: 506
出版历程
- 收稿日期: 2010-07-06
- 修回日期: 2010-08-22
- 刊出日期: 2011-08-15

Temperature Change and Microstructure Evolution of the Bore Penetrated by Copper Jets

CHEN Hao,
TAO Gang

School of Energy and Power Engineering, Nanjing University of Science and Technology, Nanjing 210094, China

More Information

Corresponding author: CHEN Hao

摘要

摘要: 分析金属射流侵彻钢靶后钢靶孔壁上残留的射流材料的微观组织，将有助于了解射流的超塑性动态变形以及射流在侵彻和冷却过程中的状态变化。通过对铜射流侵彻钢靶时钢靶侵彻孔壁处的组织进行分析，利用数值模拟和理论计算，对铜射流的侵彻过程进行研究，得到了侵彻后孔壁上铜射流的温度及晶粒度的变化曲线，分析结果与扫描电镜的观察结果吻合。通过对孔壁处铜和钢的微观组织进行观察，判断出铜射流在侵彻时没有发生熔化，而是发生了动态再结晶，并且晶粒在随后的冷却过程中发生了明显的长大，此外在铜冷却过程中也产生了孪晶。
- 射流 /
- 侵彻 /
- 动态再结晶 /
- 孪晶
Abstract: After metal jets penetrate the steel target, the jets' material adheres on the penetration channel wall. The research on the jets' material is helpful to analyzing the dynamic superplastic deformation and morphological changes of jets in the process of penetration and cooling. Theoretical computation and numerical simulation are used in this work to study the penetration process of copper jets, and the changes of temperature and grain size of copper jets adhered on the penetration channel wall are obtained. The simulated results are in good agreement with the SEM (Scanning Electron Microscope) observation. From the observation of microstructure of copper and steel, we can get the conclusion that the copper jets do not melt but instead undergo dynamic recrystallization in the process of penetration. In addition, the copper grain size increases obviously and the twins are formed in the cooling process.
- jet /
- penetration /
- dynamic recrystallization /
- twin

HTML全文

参考文献(21)

Jamet F. Investigation of Shaped Charge Jets Using Flash X-Ray Diffraction [A]//The 8th International Symposium on Ballistics [C]. Orlando, Florida, USA, 1984: 1-6.

Murr L E, Trillo E A, Pappu S, et al. Adiabatic Shear Bands and Examples of Their Role in Severe Plastic Deformation [J]. J Mater Sci, 2002, 37(16): 3337-3360.

Meyers M A, Meyer L W, Vecchio K S, et al. High Strain, High Strain-Rate Deformation of Copper [A]//Proceedings of Shock Wave and High Strain-Rate Phenomena in Materials [C]. Hongkong, 1991: 529-542.

Meyers M A, Xu Y B, Xue Q, et al. Microstructural Evolution in Adiabatic Shear Localization in Stainless Steel [J]. Acta Mater, 2003, 51(5): 1307-1325.

Chen H. The Spread of Shock Wave in Copper and Its Influence to the Microstructure [D]. Nanjing: Nanjing University of Science and Technology, 2007: 26-29. (in Chinese)

陈昊. 冲击波在铜板中的传播及对微观组织的影响 [D]. 南京: 南京理工大学, 2007: 26-29.

von Holle W G, Trimble J J. Temperature Measurement of Shocked Copper Plates and Shaped Charge Jets by Two-Color Irradiometry [J]. J Appl Phys, 1976, 47(6): 2391-2394.

Duan Z Q, Cong M H, Su H H, et al. Microstructure Investigation of the Penetration Bore of 45# Steel in High Speed Impacting [J]. Chinese Journal of Material Research, 2001, 15(4): 403-408. (in Chinese)

段占强, 丛美华, 苏会和, 等. 45#钢高速冲击穿孔的显微组织 [J]. 材料研究学报, 2001, 15(4): 403-408.

Cao B Y, Lassila D H, Schneider M S, et al. Effect of Shock Compression Method on the Defect Substructure in Monocrystalline Coppert [J]. Mater Sci Eng A, 2005, 409(1-2): 270-281.

Yang S M, Tao W Q. Heat Transfer [M]. Beijing: Higher Education Press, 2006. (in Chinese)

杨世铭, 陶文铨. 传热学 [M]. 北京: 高等教育出版社, 2006.

Meyers M A. Dynamic Behavior of Materials [M]. Translated by Zhang Q M, Liu Y, Huang F L, et al. Beijing: National Defence Industry Press, 2006. (in Chinese)

Meyers M A. 材料的动力学行为 [M]. 张庆明, 刘彦, 黄风雷, 等, 译. 北京: 国防工业出版社, 2006.

Meyers M A, Andrade U R, Chokshi A H. The Effect of Grain Size on the High-Strain, High-Strain-Rate Behavior of Copper [J]. Metall Mater Trans A, 1995, 26(11): 2881-2893.

Meyers M A, Nesterenko V F, Lasalvia J C, et al. Shear Localization in Dynamic Deformation of Materials: Microstructural Evolution and Self-Organization [J]. Mater Sci Eng A, 2001, 317(1-2): 204-225.

Mo D F, He G Q, Hu Z F, et al. Microstructure and Properties of Electron Beam Welded Joints of 18 Ni Co-Free Maraging Steel [J]. Transactions of the China Welding Institution, 2008, 29(4): 29-32. (in Chinese)

莫德锋, 何国求, 胡正飞, 等. 无钴马氏体时效钢电子束焊接接头组织与性能分析 [J]. 焊接学报, 2008, 29(4): 29-32.

Zheng Q G. Laser Advanced Manufacture [M]. Wuhan: Huazhong University of Science Technology Press, 2002. (in Chinese)

郑启光. 激光先进制造技术 [M]. 武汉: 华中科技大学出版社, 2002.

Murr L E, Meyers M A, Niou C S, et al. Shock-Induced Deformation Twinning in Tantalum [J]. Acta Mater, 1997, 45(1): 157-175.
