二级轻气炮遮挡式激光光幕测速系统

邓云飞; 张伟; 贾斌; 庞宝君; 曹宗胜

doi:10.11858/gywlxb.2011.04.002

二级轻气炮遮挡式激光光幕测速系统

doi: 10.11858/gywlxb.2011.04.002

哈尔滨工业大学空间碎片高速撞击研究中心，黑龙江哈尔滨 150080

详细信息

通讯作者:
邓云飞

计量
- 文章访问数: 8174
- HTML全文浏览量: 518
- PDF下载量: 536
出版历程
- 收稿日期: 2010-04-18
- 修回日期: 2010-07-08
- 刊出日期: 2011-08-15

A System for Measuring Two-Stage Light Gas Gun Projectile Velocity with Laser Screen and Photodetector

Hypervelocity Impact Research Center, Harbin Institute of Technology, Harbin 150080, China

More Information

Corresponding author: DENG Yun-Fei

摘要

摘要: 研制了用于测量二级轻气炮毫米级弹丸速度的遮挡式激光测速系统。该系统主要包括测速平台和激光测速仪，采用红光半导体激光器作光源，硅光电二极管为光电探测器。测速平台安装于炮管测速段，具有结构简单紧凑、抗振动、激光光幕易于准直和测量等特点。激光光幕高度为20 mm，避免了弹丸偏离轴线过多时因无法遮断光束导致的测速失败。运用该测速系统进行了一系列二级轻气炮测速实验，成功测量了金属弹丸和非金属弹丸的速度，测速范围为1.58～4.51 km/s。将测量数据与磁测速系统测量数据进行比较，结果表明，该激光测速系统的测量精度高、稳定性好、灵敏度高、抗干扰性强、适用范围广。
- 激光测速 /
- 二级轻气炮 /
- 半导体激光器 /
- 光电二极管
Abstract: A new velocity measurement system is set up for measuring the millimetresized projectile velocity in two-stage light gas gun. The system consists of an installation platform and a laser velocimeter which using red light semiconductor laser as lamp-house and silicon photodiode as photodetector. The platform installed in the barrel test section has numerous advantages of simple structure, aseismic design, easy adjustment and measurement. Using this new measurement system, the metallic and non-metallic projectiles velocities are successfully achieved. Moreover, the velocities of metallic projectile measured by this system are compared with those using magnetic induction sensors. The results show that this system not only has high reliability and accuracy but also high sensitivity, strong anti-interference and wide range of applications.
- laser velocity measurement /
- two-stage light gas gun /
- semicondutor laser /
- photodiode

HTML全文

参考文献(13)

Kawakita S, Hata H, Furukawa K. Development of High Velocity Projectile with Pressure Chamber [A]//Proceedings of the Twenty-Third International Symposium on Space Technology and Science [C]. Tokyo, Japan, 2002: 2490-2494.

Zhang Z C, Feng D R, Shi J J, et al. Practice of Studying Rock Damage by One-Stage Compressing Light Gas Gun Technology [J]. Mining Processing Equipment, 2005, 33(8): 9-11. (in Chinese)

张志呈, 冯德润, 史瑾瑾, 等. 单级压缩轻气炮技术研究岩石损伤的实践 [J]. 矿山机械, 2005, 33(8): 9-11.

Zhang D Z, Tang R D, Lin J D, et al. Development of a New Type Gas-Driven Two-Stage Light Gas Gun [J]. Acta Armamentarii, 2004, 25(1): 14-18. (in Chinese)

张德志, 唐润棣, 林俊德, 等. 新型气体驱动二级轻气炮研制 [J]. 兵工学报, 2004, 25(1): 14-18.

Zhang W B. Velocity Measurement Technologies of Space Debris Driven by Ground-Base Simulation Devices [J]. Spacecraft Environment Engineering, 2006, 23(3): 138-141. (in Chinese)

张文兵. 地基模拟空间碎片速度测试技术 [J]. 航天器环境工程, 2006, 23(3): 138-141.

Zhao J W, Hu Z Y, Zhao X Y, et al. An Optoelectronic Device for mm-Size Projectile Velocity Measurement [J]. Chinese Journal of High Pressure Physics, 2009, 23(5): 395-400. (in Chinese)

赵军卫, 胡志云, 赵新燕, 等. 用于毫米级弹丸速度测量的光电检测装置 [J]. 高压物理学报, 2009, 23(5): 395-400.

Shi Y C, Liu F Q. A Laser System for Measuring the Projectile Velocity in Gas Gun [J]. Explosion and Shock Waves, 1986, 6(1): 71-79. (in Chinese)

史有程, 刘风琴. 一个测量气体炮弹速的激光测量装置 [J]. 爆炸与冲击, 1986, 6(1): 71-79.

Zhang G J, Tian C J, He P. The Projectile Impacting Velocity Measurement Technique with Splitting Laser Beams [J]. Chinese Journal of High Pressure Physics, 1997, 11(2): 156-160. (in Chinese)

张光军, 田常津, 何鹏. 弹体撞击速度的激光分束测量技术 [J]. 高压物理学报, 1997, 11(2): 156-160.
